Detail produk:
Syarat-syarat pembayaran & pengiriman:
|
| Density: | 16667 dots per sqm | LED Type: | SMD3528 |
|---|---|---|---|
| Module size: | 480mmX320 mm | Cabinet size: | 960mmX640mm |
| Warranty: | 2 Year | OEM: | Yes |
| Color: | Full color | Transparent Rate: | 85% |
| Brightness: | >6000nits/sqm | refresh rate: | >1920hz |
| Cahaya Tinggi: | transparent led display,transparent video display |
||
Lightweight Glass Window Transparent Led Screen Video Display High Brightness
1. Transparent design, meet your diffrent requirements.
2. High brightness ≥ 6000 nits/sqm, automatically brightness adjust to environment.
Features:
1. Low investment and high return.
2. Easy installation and maintenance.
3. Blend the design with newly renovated places or buildings, enhance the quality of the property.
4. High transparency >85%.
5. Energy-saving and low consumption.
A transparent digital poster is the best advertising solution for any shop window! Because you can update the contents easily and it won’t block any lighting like printed posters.
As we know these posters are perfect for public places such as commercial plazas, commercial streets, airports, museums, exhibitions, shopping malls, supermarkets, theaters, hotels, etc.
The highest density transparent LED display available. This display can read almost any video and image format, such as jpg, png, mov, wmv mp4, etc. You can remotely control, monitor and update content from a control server. You can make sure your customers are instant and synchronized with their new sign!
Trade terms:
1. Hardware: LED screen and video controlling system
2. Technical material: English version user manual, installation manual, and maintenance manual
3. Service: Provide free technology support by phone and e-mail
4. 2 years guarantee
5. Packing: Anti-shaking wooden package or Air Flight Case
6. Transportation: By sea or air or Express
Our service
1. Your inquiry related to our products or price will be replied in 24hrs
2. The size can be change as you give.
3. What we show is some of our current models, welcome to give us your own ideas.
4. Protection of your sales area, ideas of design and all your private information
5. (Top Quality) + (Reasonable Price) + (Responsible After Service) = (Successful & Win)
Applications:
public places such as commercial plazas, commercial streets, airports, museums, exhibitions, shopping malls, supermarkets, theaters, hotels, etc.
Specifications:
| Product Model | P7.5mm | |||||
| Module size | 480mm*320mm | |||||
| Pixel pitch | P7.5/8mm | |||||
| Pixel density | 16667dots/sqm | |||||
| Pixel configuration | SMD 3in1 | |||||
| Module resolution | 64dots(W)*48dots(H) | |||||
| Module Thickness | 2CM | |||||
| Driving method | Constant Current Driving | |||||
| Scanning method | 1/4 scan | |||||
| Brightness | ≥6000nits/sqm | |||||
| The specifications of cabinets | ||||||
| Cabinet size | 960mm*640mm | |||||
| Module quantity | 4pcs | |||||
| Power supply | 5V/60A | |||||
| Cabinet resolution | 128*96dots | |||||
| Optimal viewing distance | 8M~50M | |||||
| Optimal viewing angle | 160°(W) 120°(H) | |||||
| RHWorking temperature | (Work :-20°C~+60°C) | |||||
| System operating humility | 10%-95% | |||||
| The specifications of power supplier | ||||||
| Operating Voltage | AC110V / 220V±10% | |||||
| Average power consumption | 400W/H | |||||
| Maximum power consumption | ≤600W/m2 | |||||
| Electric current | ≤20mA(single LED) | |||||
| The specifications of control card | ||||||
| Control Panels | Pentium4 or above P4 or above | |||||
| Operating system | WIN98/2000/NT/XP | |||||
| Control model | Synchronization with PC | |||||
| The specifications of the main technical parameters | ||||||
| Driving device | Constant Current Driving | |||||
| Refresh rate | ≥1920HZ | |||||
| Grey scale | RGB Each 256, can display 16.7M colors) | |||||
| MTBF | ≥10000hours | |||||
| Power switch | Automatic Switch | |||||
| Display Mode | 800*600/1024*768/1280*900 | |||||
